DC Input AZ Series 2.36 in. (60 mm) NEMA 24 Stepper Motors with Absolute Encoders
2.36 in. (60 mm) AZ Series Stepper Motors with Absolute Encoders
The AlphaStep AZ Series stepper motor offers closed loop control, substantially reduces heat generation from the motor and by incorporating the newly developed Mechanical Absolute Encoder, absolute-type positioning is available, without battery back-up or external sensors to buy. Requires AlphaStep AZ Series Driver.
- 2.36 in. (60 mm) Frame Size
- Battery-Free, Mechanical Absolute Encoder
- DC Input
- 3 motor only shaft types: Round, Flat and Key
- Geared Type Available
- Electromagnetic Brake Type Available
Item # |
Frame Size |
Driver Voltage Input Power |
Speed-Torque Characteristics |
Holding Torque |
Shaft/Gear Type |
Gear Ratio (X:1) |
Shaft |
Electromagnetic Brake |
Connection Type |
Cable Direction |
Web Price |
CAD |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| AZM69M0K / PLE60-5A / P00025 AZM69M0K / PLE60-5A / P00025/Asset/azm66-ple-600px.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
 Speed - Torque Charcteristics |
Holding Torque 1416.1 oz-in | Shaft/Gear Type Planetary Gear | Gear Ratio (X:1) 5 :1 | Shaft Single | Electromagnetic Brake Equipped | Connection Type Cable | Cable Direction - | $1,027.50 | CAD - ORIENTAL_2102665461:AZM69M0K%20/%20PLE60-5A%20/%20P00025 |
| AZM69M0K / PLE60-10A / P00025 AZM69M0K / PLE60-10A / P00025/Asset/azm66-ple-600px.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
 Speed - Torque Charcteristics |
Holding Torque 2124.2 oz-in | Shaft/Gear Type Planetary Gear | Gear Ratio (X:1) 10 :1 | Shaft Single | Electromagnetic Brake Equipped | Connection Type Cable | Cable Direction - | $1,027.50 | CAD - ORIENTAL_2102665461:AZM69M0K%20/%20PLE60-10A%20/%20P00025 |
| AZM69M0K / PLE60-20A / P00025 AZM69M0K / PLE60-20A / P00025/Asset/azm66-ple-600px.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
 Speed - Torque Charcteristics |
Holding Torque 5664.5 oz-in | Shaft/Gear Type Planetary Gear | Gear Ratio (X:1) 20 :1 | Shaft Single | Electromagnetic Brake Equipped | Connection Type Cable | Cable Direction - | $1,106.50 | CAD - ORIENTAL_2102665461:AZM69M0K%20/%20PLE60-20A%20/%20P00025 |
| AZM69M0K / PLE60-40A / P00025 AZM69M0K / PLE60-40A / P00025/Asset/azm66-ple-600px.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
 Speed - Torque Charcteristics |
Holding Torque 5664.5 oz-in | Shaft/Gear Type Planetary Gear | Gear Ratio (X:1) 40 :1 | Shaft Single | Electromagnetic Brake Equipped | Connection Type Cable | Cable Direction - | $1,106.50 | CAD - ORIENTAL_2102665461:AZM69M0K%20/%20PLE60-40A%20/%20P00025 |
| AZM66AK-FC7.2DA AZM66AK-FC7.2DA/Asset/azm66ac-fc7_2da-img.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
 |
Holding Torque 352 oz-in | Shaft/Gear Type Right-Angle Spur / Face Gear | Gear Ratio (X:1) 7.2 :1 | Shaft Single | Electromagnetic Brake Not Equipped | Connection Type Cable | Cable Direction Down | $855.00 | CAD - ORIENTAL_2102665461:AZM66AK-FC7.2DA |
| AZM66AK-FC10DA AZM66AK-FC10DA/Asset/azm66ac-fc7_2da-img.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
 |
Holding Torque 480 oz-in | Shaft/Gear Type Right-Angle Spur / Face Gear | Gear Ratio (X:1) 10 :1 | Shaft Single | Electromagnetic Brake Not Equipped | Connection Type Cable | Cable Direction Down | $855.00 | CAD - ORIENTAL_2102665461:AZM66AK-FC10DA |
| AZM66AK-FC20DA AZM66AK-FC20DA/Asset/azm66ac-fc7_2da-img.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
 |
Holding Torque 976 oz-in | Shaft/Gear Type Right-Angle Spur / Face Gear | Gear Ratio (X:1) 20 :1 | Shaft Single | Electromagnetic Brake Not Equipped | Connection Type Cable | Cable Direction Down | $855.00 | CAD - ORIENTAL_2102665461:AZM66AK-FC20DA |
| AZM66AK-FC30DA AZM66AK-FC30DA/Asset/azm66ac-fc7_2da-img.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
 |
Holding Torque 1472 oz-in | Shaft/Gear Type Right-Angle Spur / Face Gear | Gear Ratio (X:1) 30 :1 | Shaft Single | Electromagnetic Brake Not Equipped | Connection Type Cable | Cable Direction Down | $855.00 | CAD - ORIENTAL_2102665461:AZM66AK-FC30DA |
| AZM66AK-FC7.2UA AZM66AK-FC7.2UA/Asset/azm66ac-fc7_2ua-img.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
|
Holding Torque 352 oz-in | Shaft/Gear Type Right-Angle Spur / Face Gear | Gear Ratio (X:1) 7.2 :1 | Shaft Single | Electromagnetic Brake Not Equipped | Connection Type Cable | Cable Direction Up | $855.00 | CAD - ORIENTAL_2102665461:AZM66AK-FC7.2UA |
| AZM66AK-FC10UA AZM66AK-FC10UA/Asset/azm66ac-fc7_2ua-img.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
|
Holding Torque 480 oz-in | Shaft/Gear Type Right-Angle Spur / Face Gear | Gear Ratio (X:1) 10 :1 | Shaft Single | Electromagnetic Brake Not Equipped | Connection Type Cable | Cable Direction Up | $855.00 | CAD - ORIENTAL_2102665461:AZM66AK-FC10UA |
| AZM66AK-FC20UA AZM66AK-FC20UA/Asset/azm66ac-fc7_2ua-img.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
|
Holding Torque 976 oz-in | Shaft/Gear Type Right-Angle Spur / Face Gear | Gear Ratio (X:1) 20 :1 | Shaft Single | Electromagnetic Brake Not Equipped | Connection Type Cable | Cable Direction Up | $855.00 | CAD - ORIENTAL_2102665461:AZM66AK-FC20UA |
| AZM66AK-FC30UA AZM66AK-FC30UA/Asset/azm66ac-fc7_2ua-img.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
|
Holding Torque 1472 oz-in | Shaft/Gear Type Right-Angle Spur / Face Gear | Gear Ratio (X:1) 30 :1 | Shaft Single | Electromagnetic Brake Not Equipped | Connection Type Cable | Cable Direction Up | $855.00 | CAD - ORIENTAL_2102665461:AZM66AK-FC30UA |
| AZM66MK-FC7.2DA AZM66MK-FC7.2DA/Asset/azm66mc-fc7_2da-img.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
|
Holding Torque 352 oz-in | Shaft/Gear Type Right-Angle Spur / Face Gear | Gear Ratio (X:1) 7.2 :1 | Shaft Single | Electromagnetic Brake Equipped | Connection Type Cable | Cable Direction Down | $1,106.00 | CAD - ORIENTAL_2102665461:AZM66MK-FC7.2DA |
| AZM66MK-FC10DA AZM66MK-FC10DA/Asset/azm66mc-fc7_2da-img.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
|
Holding Torque 480 oz-in | Shaft/Gear Type Right-Angle Spur / Face Gear | Gear Ratio (X:1) 10 :1 | Shaft Single | Electromagnetic Brake Equipped | Connection Type Cable | Cable Direction Down | $1,106.00 | CAD - ORIENTAL_2102665461:AZM66MK-FC10DA |
| AZM66MK-FC20DA AZM66MK-FC20DA/Asset/azm66mc-fc7_2da-img.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
|
Holding Torque 976 oz-in | Shaft/Gear Type Right-Angle Spur / Face Gear | Gear Ratio (X:1) 20 :1 | Shaft Single | Electromagnetic Brake Equipped | Connection Type Cable | Cable Direction Down | $1,106.00 | CAD - ORIENTAL_2102665461:AZM66MK-FC20DA |
| AZM66MK-FC30DA AZM66MK-FC30DA/Asset/azm66mc-fc7_2da-img.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
|
Holding Torque 1472 oz-in | Shaft/Gear Type Right-Angle Spur / Face Gear | Gear Ratio (X:1) 30 :1 | Shaft Single | Electromagnetic Brake Equipped | Connection Type Cable | Cable Direction Down | $1,106.00 | CAD - ORIENTAL_2102665461:AZM66MK-FC30DA |
| AZM66MK-FC7.2UA AZM66MK-FC7.2UA/Asset/azm66mc-fc7_2ua-img.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
|
Holding Torque 352 oz-in | Shaft/Gear Type Right-Angle Spur / Face Gear | Gear Ratio (X:1) 7.2 :1 | Shaft Single | Electromagnetic Brake Equipped | Connection Type Cable | Cable Direction Up | $1,106.00 | CAD - ORIENTAL_2102665461:AZM66MK-FC7.2UA |
| AZM66MK-FC10UA AZM66MK-FC10UA/Asset/azm66mc-fc7_2ua-img.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
|
Holding Torque 480 oz-in | Shaft/Gear Type Right-Angle Spur / Face Gear | Gear Ratio (X:1) 10 :1 | Shaft Single | Electromagnetic Brake Equipped | Connection Type Cable | Cable Direction Up | $1,106.00 | CAD - ORIENTAL_2102665461:AZM66MK-FC10UA |
| AZM66MK-FC20UA AZM66MK-FC20UA/Asset/azm66mc-fc7_2ua-img.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
|
Holding Torque 976 oz-in | Shaft/Gear Type Right-Angle Spur / Face Gear | Gear Ratio (X:1) 20 :1 | Shaft Single | Electromagnetic Brake Equipped | Connection Type Cable | Cable Direction Up | $1,106.00 | CAD - ORIENTAL_2102665461:AZM66MK-FC20UA |
| AZM66MK-FC30UA AZM66MK-FC30UA/Asset/azm66mc-fc7_2ua-img.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
|
Holding Torque 1472 oz-in | Shaft/Gear Type Right-Angle Spur / Face Gear | Gear Ratio (X:1) 30 :1 | Shaft Single | Electromagnetic Brake Equipped | Connection Type Cable | Cable Direction Up | $1,106.00 | CAD - ORIENTAL_2102665461:AZM66MK-FC30UA |
| AZM66A0K AZM66A0K/Asset/azm66ac-img.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
 Speed - Torque Characteristics |
Holding Torque 142 oz-in | Shaft/Gear Type Round Shaft (No Gearhead) | Gear Ratio (X:1) - | Shaft Single | Electromagnetic Brake Not Equipped | Connection Type Cable | Cable Direction - | $438.00 | CAD - ORIENTAL_2102665461:AZM66A0K |
| AZM66M0K AZM66M0K/Asset/azm66mc-img.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
Speed - Torque Characteristics |
Holding Torque 142 oz-in | Shaft/Gear Type Round Shaft (No Gearhead) | Gear Ratio (X:1) - | Shaft Single | Electromagnetic Brake Equipped | Connection Type Cable | Cable Direction - | $684.00 | CAD - ORIENTAL_2102665461:AZM66M0K |
| AZM69A0K AZM69A0K/Asset/azm69ac-img.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
 Speed - Torque Characteristics |
Holding Torque 280 oz-in | Shaft/Gear Type Round Shaft (No Gearhead) | Gear Ratio (X:1) - | Shaft Single | Electromagnetic Brake Not Equipped | Connection Type Cable | Cable Direction - | $443.00 | CAD - ORIENTAL_2102665461:AZM69A0K |
| AZM69M0K AZM69M0K/Asset/azm66mc-img.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
Speed - Torque Characteristics |
Holding Torque 280 oz-in | Shaft/Gear Type Round Shaft (No Gearhead) | Gear Ratio (X:1) - | Shaft Single | Electromagnetic Brake Equipped | Connection Type Cable | Cable Direction - | $690.00 | CAD - ORIENTAL_2102665461:AZM69M0K |
| AZM66A1K AZM66A1K/Asset/azm66ac-img.jpg | Frame Size 2.36 in | Driver Voltage Input Power DC |
Speed-Torque Characteristics
Speed - Torque Characteristics |
Holding Torque 142 oz-in | Shaft/Gear Type Key Shaft (No Gearhead) | Gear Ratio (X:1) - | Shaft Single | Electromagnetic Brake Not Equipped | Connection Type Cable | Cable Direction - | $451.00 | CAD - ORIENTAL_2102665461:AZM66A1K |
