3.35 in. (85 mm) NEMA 34 PKP Series 2-Phase Unipolar Stepper Motors

The high-torque PKP series stepper motor offers balanced performance enhanced by high torque, low vibration and low noise.

3.35 in. (85 mm) Frame Sizes
2-phase, Unipolar
Single or Double Shaft
Max. Holding Torque

Round Shaft Type = 368 ~ 1024 oz-in (2.6 ~ 7.3 N·m)

1 - 25 of 32 | Results Per Page | View | Unit of Measure

1 2

Request Information Compare Items Search by Specification

Clear Filter

Current per Phase (A/phase)

Shaft/Gear Type

Round Shaft with Flat (No Gearhead)

Output Shaft

Imperial
Metric

Shaft

Single
Double

Item #	Basic Step Angle	Frame Size	Motor Length	Holding Torque	Current per Phase (A/phase)	Shaft/Gear Type	Gear Ratio (X:1)	Output Shaft	Output Shaft Diameter	Shaft	Lead Wires	Web Price

PKP296U20AA	- 1.8º	- 3.35 in85 mm	- 2.6 in.66 mm	- 368 oz-in2.6 N·m	- 2	- Round Shaft with Flat (No Gearhead)	-	- Imperial	- 1/2 in.	- Single	- 6	$130.00
PKP296U20BA	- 1.8º	- 3.35 in85 mm	- 2.6 in.66 mm	- 368 oz-in2.6 N·m	- 2	- Round Shaft with Flat (No Gearhead)	-	- Imperial	- 1/2 in.	- Double	- 6	$134.00
PKP296U30AA	- 1.8º	- 3.35 in85 mm	- 2.6 in.66 mm	- 368 oz-in2.6 N·m	- 3	- Round Shaft with Flat (No Gearhead)	-	- Imperial	- 1/2 in.	- Single	- 6	$130.00
PKP296U30BA	- 1.8º	- 3.35 in85 mm	- 2.6 in.66 mm	- 368 oz-in2.6 N·m	- 3	- Round Shaft with Flat (No Gearhead)	-	- Imperial	- 1/2 in.	- Double	- 6	$134.00
PKP296U45AA	- 1.8º	- 3.35 in85 mm	- 2.6 in.66 mm	- 368 oz-in2.6 N·m	- 4.5	- Round Shaft with Flat (No Gearhead)	-	- Imperial	- 1/2 in.	- Single	- 6	$130.00
PKP296U45BA	- 1.8º	- 3.35 in85 mm	- 2.6 in.66 mm	- 368 oz-in2.6 N·m	- 4.5	- Round Shaft with Flat (No Gearhead)	-	- Imperial	- 1/2 in.	- Double	- 6	$134.00
PKP299U20AA	- 1.8º	- 3.35 in85 mm	- 3.78 in.96 mm	- 704 oz-in5 N·m	- 2	- Round Shaft with Flat (No Gearhead)	-	- Imperial	- 1/2 in.	- Single	- 6	$200.00
PKP299U20BA	- 1.8º	- 3.35 in85 mm	- 3.78 in.96 mm	- 704 oz-in5 N·m	- 2	- Round Shaft with Flat (No Gearhead)	-	- Imperial	- 1/2 in.	- Double	- 6	$206.00
PKP299U30AA	- 1.8º	- 3.35 in85 mm	- 3.78 in.96 mm	- 704 oz-in5 N·m	- 3	- Round Shaft with Flat (No Gearhead)	-	- Imperial	- 1/2 in.	- Single	- 6	$200.00
PKP299U30BA	- 1.8º	- 3.35 in85 mm	- 3.78 in.96 mm	- 704 oz-in5 N·m	- 3	- Round Shaft with Flat (No Gearhead)	-	- Imperial	- 1/2 in.	- Double	- 6	$206.00
PKP299U45AA	- 1.8º	- 3.35 in85 mm	- 3.78 in.96 mm	- 704 oz-in5 N·m	- 4.5	- Round Shaft with Flat (No Gearhead)	-	- Imperial	- 1/2 in.	- Single	- 6	$200.00
PKP299U45BA	- 1.8º	- 3.35 in85 mm	- 3.78 in.96 mm	- 704 oz-in5 N·m	- 4.5	- Round Shaft with Flat (No Gearhead)	-	- Imperial	- 1/2 in.	- Double	- 6	$206.00
PKP2913U20AA	- 1.8º	- 3.35 in85 mm	- 4.96 in.126 mm	- 1024 oz-in7.3 N·m	- 2	- Round Shaft with Flat (No Gearhead)	-	- Imperial	- 1/2 in.	- Single	- 6	$253.00
PKP2913U20BA	- 1.8º	- 3.35 in85 mm	- 4.96 in.126 mm	- 1024 oz-in7.3 N·m	- 2	- Round Shaft with Flat (No Gearhead)	-	- Imperial	- 1/2 in.	- Double	- 6	$263.00
PKP2913U40AA	- 1.8º	- 3.35 in85 mm	- 4.96 in.126 mm	- 1024 oz-in7.3 N·m	- 4	- Round Shaft with Flat (No Gearhead)	-	- Imperial	- 1/2 in.	- Single	- 6	$253.00
PKP2913U40BA	- 1.8º	- 3.35 in85 mm	- 4.96 in.126 mm	- 1024 oz-in7.3 N·m	- 4	- Round Shaft with Flat (No Gearhead)	-	- Imperial	- 1/2 in.	- Double	- 6	$263.00
PKP296U20A	- 1.8º	- 3.35 in85 mm	- 2.6 in.66 mm	- 368 oz-in2.6 N·m	- 2	- Round Shaft with Flat (No Gearhead)	-	- Metric	- 14 mm	- Single	- 6	$130.00
PKP296U20B	- 1.8º	- 3.35 in85 mm	- 2.6 in.66 mm	- 368 oz-in2.6 N·m	- 2	- Round Shaft with Flat (No Gearhead)	-	- Metric	- 14 mm	- Double	- 6	$134.00
PKP296U30A	- 1.8º	- 3.35 in85 mm	- 2.6 in.66 mm	- 368 oz-in2.6 N·m	- 3	- Round Shaft with Flat (No Gearhead)	-	- Metric	- 14 mm	- Single	- 6	$130.00
PKP296U30B	- 1.8º	- 3.35 in85 mm	- 2.6 in.66 mm	- 368 oz-in2.6 N·m	- 3	- Round Shaft with Flat (No Gearhead)	-	- Metric	- 14 mm	- Double	- 6	$134.00
PKP296U45A	- 1.8º	- 3.35 in85 mm	- 2.6 in.66 mm	- 368 oz-in2.6 N·m	- 4.5	- Round Shaft with Flat (No Gearhead)	-	- Metric	- 14 mm	- Single	- 6	$130.00
PKP296U45B	- 1.8º	- 3.35 in85 mm	- 2.6 in.66 mm	- 368 oz-in2.6 N·m	- 4.5	- Round Shaft with Flat (No Gearhead)	-	- Metric	- 14 mm	- Double	- 6	$134.00
PKP299U20A	- 1.8º	- 3.35 in85 mm	- 3.78 in.96 mm	- 704 oz-in5 N·m	- 2	- Round Shaft with Flat (No Gearhead)	-	- Metric	- 14 mm	- Single	- 6	$200.00
PKP299U20B	- 1.8º	- 3.35 in85 mm	- 3.78 in.96 mm	- 704 oz-in5 N·m	- 2	- Round Shaft with Flat (No Gearhead)	-	- Metric	- 14 mm	- Double	- 6	$206.00
PKP299U30A	- 1.8º	- 3.35 in85 mm	- 3.78 in.96 mm	- 704 oz-in5 N·m	- 3	- Round Shaft with Flat (No Gearhead)	-	- Metric	- 14 mm	- Single	- 6	$200.00
