Item # |
Actuator Frame Size |
Type |
Cable Direction |
Mount |
Ball Screw Cover |
Lead |
Max. Vertical Transportable Mass |
Max. Thrust Force |
Max. Holding Force |
Web Price |
CAD |
|---|---|---|---|---|---|---|---|---|---|---|---|
| DR28T2.5BC03-AZAKD DR28T2.5BC03-AZAKD/Asset/dr28t2_5bc03-azakr-img.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Down | Mount - Not Equipped | Ball Screw Cover - Equipped | Lead - 2.5 mm | Max. Vertical Transportable Mass - 2 kg | Max. Thrust Force - 20 N | Max. Holding Force - 20 N | $1,701.00 | CAD - ORIENTAL_2102665461:DR28T2.5BC03-AZAKD |
| DR28T2.5BC03-AZAKD-F DR28T2.5BC03-AZAKD-F/Asset/dr28t2-5bc03-azak-f_d.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Down | Mount - Flange Mount | Ball Screw Cover - Equipped | Lead - 2.5 mm | Max. Vertical Transportable Mass - 2 kg | Max. Thrust Force - 20 N | Max. Holding Force - 20 N | $1,756.00 | CAD - ORIENTAL_2102665461:DR28T2.5BC03-AZAKD-F |
| DR28T2.5BC03-AZAKD-P DR28T2.5BC03-AZAKD-P/Asset/dr28t2-5bc03-azak-p_d.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Down | Mount - Foot Mount | Ball Screw Cover - Equipped | Lead - 2.5 mm | Max. Vertical Transportable Mass - 2 kg | Max. Thrust Force - 20 N | Max. Holding Force - 20 N | $1,756.00 | CAD - ORIENTAL_2102665461:DR28T2.5BC03-AZAKD-P |
| DR28T2.5BC03-AZAKL DR28T2.5BC03-AZAKL/Asset/dr28t2_5bc03-azakr-img.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Left | Mount - Not Equipped | Ball Screw Cover - Equipped | Lead - 2.5 mm | Max. Vertical Transportable Mass - 2 kg | Max. Thrust Force - 20 N | Max. Holding Force - 20 N | $1,701.00 | CAD - ORIENTAL_2102665461:DR28T2.5BC03-AZAKL |
| DR28T2.5BC03-AZAKL-F DR28T2.5BC03-AZAKL-F/Asset/dr28t2-5bc03-azak-f_d.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Left | Mount - Flange Mount | Ball Screw Cover - Equipped | Lead - 2.5 mm | Max. Vertical Transportable Mass - 2 kg | Max. Thrust Force - 20 N | Max. Holding Force - 20 N | $1,756.00 | CAD - ORIENTAL_2102665461:DR28T2.5BC03-AZAKL-F |
| DR28T2.5BC03-AZAKL-P DR28T2.5BC03-AZAKL-P/Asset/dr28t2-5bc03-azak-p_d.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Left | Mount - Foot Mount | Ball Screw Cover - Equipped | Lead - 2.5 mm | Max. Vertical Transportable Mass - 2 kg | Max. Thrust Force - 20 N | Max. Holding Force - 20 N | $1,756.00 | CAD - ORIENTAL_2102665461:DR28T2.5BC03-AZAKL-P |
| DR28T2.5BC03-AZAKR DR28T2.5BC03-AZAKR/Asset/dr28t2_5bc03-azakr-img.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Right | Mount - Not Equipped | Ball Screw Cover - Equipped | Lead - 2.5 mm | Max. Vertical Transportable Mass - 2 kg | Max. Thrust Force - 20 N | Max. Holding Force - 20 N | $1,701.00 | CAD - ORIENTAL_2102665461:DR28T2.5BC03-AZAKR |
| DR28T2.5BC03-AZAKR-F DR28T2.5BC03-AZAKR-F/Asset/dr28t2-5bc03-azak-f_d.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Right | Mount - Flange Mount | Ball Screw Cover - Equipped | Lead - 2.5 mm | Max. Vertical Transportable Mass - 2 kg | Max. Thrust Force - 20 N | Max. Holding Force - 20 N | $1,756.00 | CAD - ORIENTAL_2102665461:DR28T2.5BC03-AZAKR-F |
| DR28T2.5BC03-AZAKR-P DR28T2.5BC03-AZAKR-P/Asset/dr28t2-5bc03-azak-p_d.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Right | Mount - Foot Mount | Ball Screw Cover - Equipped | Lead - 2.5 mm | Max. Vertical Transportable Mass - 2 kg | Max. Thrust Force - 20 N | Max. Holding Force - 20 N | $1,756.00 | CAD - ORIENTAL_2102665461:DR28T2.5BC03-AZAKR-P |
| DR28T2.5B03-AZAKD DR28T2.5B03-AZAKD/Asset/dr28t2.5b03-azakr-img.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Down | Mount - Not Equipped | Ball Screw Cover - Not Equipped | Lead - 2.5 mm | Max. Vertical Transportable Mass - 2 kg | Max. Thrust Force - 20 N | Max. Holding Force - 20 N | $1,672.00 | CAD - ORIENTAL_2102665461:DR28T2.5B03-AZAKD |
| DR28T2.5B03-AZAKD-F DR28T2.5B03-AZAKD-F/Asset/dr28t2-5b03-azak-f_d.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Down | Mount - Flange Mount | Ball Screw Cover - Not Equipped | Lead - 2.5 mm | Max. Vertical Transportable Mass - 2 kg | Max. Thrust Force - 20 N | Max. Holding Force - 20 N | $1,728.00 | CAD - ORIENTAL_2102665461:DR28T2.5B03-AZAKD-F |
| DR28T2.5B03-AZAKD-P DR28T2.5B03-AZAKD-P/Asset/dr28t2-5b03-azak-p_d.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Down | Mount - Foot Mount | Ball Screw Cover - Not Equipped | Lead - 2.5 mm | Max. Vertical Transportable Mass - 2 kg | Max. Thrust Force - 20 N | Max. Holding Force - 20 N | $1,728.00 | CAD - ORIENTAL_2102665461:DR28T2.5B03-AZAKD-P |
| DR28T2.5B03-AZAKL DR28T2.5B03-AZAKL/Asset/dr28t2.5b03-azakr-img.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Left | Mount - Not Equipped | Ball Screw Cover - Not Equipped | Lead - 2.5 mm | Max. Vertical Transportable Mass - 2 kg | Max. Thrust Force - 20 N | Max. Holding Force - 20 N | $1,672.00 | CAD - ORIENTAL_2102665461:DR28T2.5B03-AZAKL |
| DR28T2.5B03-AZAKL-F DR28T2.5B03-AZAKL-F/Asset/dr28t2-5b03-azak-f_d.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Left | Mount - Flange Mount | Ball Screw Cover - Not Equipped | Lead - 2.5 mm | Max. Vertical Transportable Mass - 2 kg | Max. Thrust Force - 20 N | Max. Holding Force - 20 N | $1,728.00 | CAD - ORIENTAL_2102665461:DR28T2.5B03-AZAKL-F |
| DR28T2.5B03-AZAKL-P DR28T2.5B03-AZAKL-P/Asset/dr28t2-5b03-azak-p_d.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Left | Mount - Foot Mount | Ball Screw Cover - Not Equipped | Lead - 2.5 mm | Max. Vertical Transportable Mass - 2 kg | Max. Thrust Force - 20 N | Max. Holding Force - 20 N | $1,728.00 | CAD - ORIENTAL_2102665461:DR28T2.5B03-AZAKL-P |
| DR28T2.5B03-AZAKR DR28T2.5B03-AZAKR/Asset/dr28t2.5b03-azakr-img.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Right | Mount - Not Equipped | Ball Screw Cover - Not Equipped | Lead - 2.5 mm | Max. Vertical Transportable Mass - 2 kg | Max. Thrust Force - 20 N | Max. Holding Force - 20 N | $1,672.00 | CAD - ORIENTAL_2102665461:DR28T2.5B03-AZAKR |
| DR28T2.5B03-AZAKR-F DR28T2.5B03-AZAKR-F/Asset/dr28t2-5b03-azak-f_d.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Right | Mount - Flange Mount | Ball Screw Cover - Not Equipped | Lead - 2.5 mm | Max. Vertical Transportable Mass - 2 kg | Max. Thrust Force - 20 N | Max. Holding Force - 20 N | $1,728.00 | CAD - ORIENTAL_2102665461:DR28T2.5B03-AZAKR-F |
| DR28T2.5B03-AZAKR-P DR28T2.5B03-AZAKR-P/Asset/dr28t2-5b03-azak-p_d.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Right | Mount - Foot Mount | Ball Screw Cover - Not Equipped | Lead - 2.5 mm | Max. Vertical Transportable Mass - 2 kg | Max. Thrust Force - 20 N | Max. Holding Force - 20 N | $1,728.00 | CAD - ORIENTAL_2102665461:DR28T2.5B03-AZAKR-P |
| DR28T1B03-AZAKD DR28T1B03-AZAKD/Asset/dr28t2.5b03-azakr-img.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Down | Mount - Not Equipped | Ball Screw Cover - Not Equipped | Lead - 1 mm | Max. Vertical Transportable Mass - 4 kg | Max. Thrust Force - 40 N | Max. Holding Force - 40 N | $1,672.00 | CAD - ORIENTAL_2102665461:DR28T1B03-AZAKD |
| DR28T1B03-AZAKD-F DR28T1B03-AZAKD-F/Asset/dr28t2-5b03-azak-f_d.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Down | Mount - Flange Mount | Ball Screw Cover - Not Equipped | Lead - 1 mm | Max. Vertical Transportable Mass - 4 kg | Max. Thrust Force - 40 N | Max. Holding Force - 40 N | $1,728.00 | CAD - ORIENTAL_2102665461:DR28T1B03-AZAKD-F |
| DR28T1B03-AZAKD-P DR28T1B03-AZAKD-P/Asset/dr28t2-5b03-azak-p_d.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Down | Mount - Foot Mount | Ball Screw Cover - Not Equipped | Lead - 1 mm | Max. Vertical Transportable Mass - 4 kg | Max. Thrust Force - 40 N | Max. Holding Force - 40 N | $1,728.00 | CAD - ORIENTAL_2102665461:DR28T1B03-AZAKD-P |
| DR28T1B03-AZAKL DR28T1B03-AZAKL/Asset/dr28t2.5b03-azakr-img.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Left | Mount - Not Equipped | Ball Screw Cover - Not Equipped | Lead - 1 mm | Max. Vertical Transportable Mass - 4 kg | Max. Thrust Force - 40 N | Max. Holding Force - 40 N | $1,672.00 | CAD - ORIENTAL_2102665461:DR28T1B03-AZAKL |
| DR28T1B03-AZAKL-F DR28T1B03-AZAKL-F/Asset/dr28t2-5b03-azak-f_d.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Left | Mount - Flange Mount | Ball Screw Cover - Not Equipped | Lead - 1 mm | Max. Vertical Transportable Mass - 4 kg | Max. Thrust Force - 40 N | Max. Holding Force - 40 N | $1,728.00 | CAD - ORIENTAL_2102665461:DR28T1B03-AZAKL-F |
| DR28T1B03-AZAKL-P DR28T1B03-AZAKL-P/Asset/dr28t2-5b03-azak-p_d.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Left | Mount - Foot Mount | Ball Screw Cover - Not Equipped | Lead - 1 mm | Max. Vertical Transportable Mass - 4 kg | Max. Thrust Force - 40 N | Max. Holding Force - 40 N | $1,728.00 | CAD - ORIENTAL_2102665461:DR28T1B03-AZAKL-P |
| DR28T1B03-AZAKR DR28T1B03-AZAKR/Asset/dr28t2.5b03-azakr-img.jpg | Actuator Frame Size - 28 mm | Type - Table Type | Cable Direction - Right | Mount - Not Equipped | Ball Screw Cover - Not Equipped | Lead - 1 mm | Max. Vertical Transportable Mass - 4 kg | Max. Thrust Force - 40 N | Max. Holding Force - 40 N | $1,672.00 | CAD - ORIENTAL_2102665461:DR28T1B03-AZAKR |
