The αSTEP AZ Series stepper motor offers closed loop control, substantially reduces heat generation from the motor and by incorporating the newly developed Mechanical Absolute Encoder, absolute-type positioning is available, without battery back-up or external sensors to buy. Requires αSTEP AZ Series Driver.
Item # |
Frame Size |
Driver Voltage Input Power |
Speed-Torque Characteristics |
Holding Torque |
Shaft/Gear Type |
Gear Ratio (X:1) |
Shaft |
Electromagnetic Brake |
Connection Type |
Cable Direction |
Web Price |
CAD |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| AZM46AKH-TS3.6 AZM46AKH-TS3.6/Asset/azm46akh-ts___-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 Speed - Torque Characteristics |
Holding Torque - 92 oz-in0.65 N·m | Shaft/Gear Type - Taper Hobbed Gear | Gear Ratio (X:1) - 3.6 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Down | $570.00 | CAD - |
| AZM46AKH-TS3.6L AZM46AKH-TS3.6L/Asset/azm46a_h-ts3__-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
Speed - Torque Characteristics |
Holding Torque - 92 oz-in0.65 N·m | Shaft/Gear Type - Taper Hobbed Gear | Gear Ratio (X:1) - 3.6 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Left | $570.00 | CAD - |
| AZM46AKH-TS3.6R AZM46AKH-TS3.6R/Asset/azm46akh-ts___-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
Speed - Torque Characteristics |
Holding Torque - 92 oz-in0.65 N·m | Shaft/Gear Type - Taper Hobbed Gear | Gear Ratio (X:1) - 3.6 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Right | $570.00 | CAD - |
| AZM46AKH-TS3.6U AZM46AKH-TS3.6U/Asset/azm46akh-ts___-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
Speed - Torque Characteristics |
Holding Torque - 92 oz-in0.65 N·m | Shaft/Gear Type - Taper Hobbed Gear | Gear Ratio (X:1) - 3.6 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Up | $570.00 | CAD - |
| AZM46AKH-TS30 AZM46AKH-TS30/Asset/azm46akh-ts___-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 Speed - Torque Characteristics |
Holding Torque - 320 oz-in2.30 N·m | Shaft/Gear Type - Taper Hobbed Gear | Gear Ratio (X:1) - 30 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Down | $589.00 | CAD - |
| AZM46AKH-TS30L AZM46AKH-TS30L/Asset/azm46a_h-ts3__-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
Speed - Torque Characteristics |
Holding Torque - 320 oz-in2.30 N·m | Shaft/Gear Type - Taper Hobbed Gear | Gear Ratio (X:1) - 30 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Left | $589.00 | CAD - |
| AZM46AKH-TS30R AZM46AKH-TS30R/Asset/azm46akh-ts___-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
Speed - Torque Characteristics |
Holding Torque - 320 oz-in2.30 N·m | Shaft/Gear Type - Taper Hobbed Gear | Gear Ratio (X:1) - 30 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Right | $589.00 | CAD - |
| AZM46AKH-TS30U AZM46AKH-TS30U/Asset/azm46akh-ts___-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
Speed - Torque Characteristics |
Holding Torque - 320 oz-in2.30 N·m | Shaft/Gear Type - Taper Hobbed Gear | Gear Ratio (X:1) - 30 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Up | $589.00 | CAD - |
| AZM46AKH-TS7.2 AZM46AKH-TS7.2/Asset/azm46akh-ts___-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 Speed - Torque Characteristics |
Holding Torque - 170 oz-in1.20 N·m | Shaft/Gear Type - Taper Hobbed Gear | Gear Ratio (X:1) - 7.2 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Down | $570.00 | CAD - |
| AZM46AKH-TS7.2L AZM46AKH-TS7.2L/Asset/azm46a_h-ts3__-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
Speed - Torque Characteristics |
Holding Torque - 170 oz-in1.20 N·m | Shaft/Gear Type - Taper Hobbed Gear | Gear Ratio (X:1) - 7.2 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Left | $570.00 | CAD - |
| AZM46AKH-TS7.2R AZM46AKH-TS7.2R/Asset/azm46akh-ts___-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
Speed - Torque Characteristics |
Holding Torque - 170 oz-in1.20 N·m | Shaft/Gear Type - Taper Hobbed Gear | Gear Ratio (X:1) - 7.2 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Right | $570.00 | CAD - |
| AZM46AKH-TS7.2U AZM46AKH-TS7.2U/Asset/azm46akh-ts___-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
Speed - Torque Characteristics |
Holding Torque - 170 oz-in1.20 N·m | Shaft/Gear Type - Taper Hobbed Gear | Gear Ratio (X:1) - 7.2 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Up | $570.00 | CAD - |
| AZM46MKH-FC10DA AZM46MKH-FC10DA/Asset/azm46mkh-fc__da-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 |
Holding Torque - 142 oz-in1 N·m | Shaft/Gear Type - Right-Angle Spur / Face Gear | Gear Ratio (X:1) - 10 :1 | Shaft - Single | Electromagnetic Brake - Equipped | Connection Type - Connector | Cable Direction - Down | $942.00 | CAD - |
| AZM46MKH-FC10UA AZM46MKH-FC10UA/Asset/azm46mch-fc_ua-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
|
Holding Torque - 142 oz-in1 N·m | Shaft/Gear Type - Right-Angle Spur / Face Gear | Gear Ratio (X:1) - 10 :1 | Shaft - Single | Electromagnetic Brake - Equipped | Connection Type - Connector | Cable Direction - Up | $942.00 | CAD - |
| AZM46MKH-FC20DA AZM46MKH-FC20DA/Asset/azm46mkh-fc__da-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 |
Holding Torque - 280 oz-in2 N·m | Shaft/Gear Type - Right-Angle Spur / Face Gear | Gear Ratio (X:1) - 20 :1 | Shaft - Single | Electromagnetic Brake - Equipped | Connection Type - Connector | Cable Direction - Down | $942.00 | CAD - |
| AZM46MKH-FC20UA AZM46MKH-FC20UA/Asset/azm46mch-fc_ua-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
|
Holding Torque - 280 oz-in2 N·m | Shaft/Gear Type - Right-Angle Spur / Face Gear | Gear Ratio (X:1) - 20 :1 | Shaft - Single | Electromagnetic Brake - Equipped | Connection Type - Connector | Cable Direction - Up | $942.00 | CAD - |
| AZM46MKH-FC30DA AZM46MKH-FC30DA/Asset/azm46mkh-fc__da-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 |
Holding Torque - 420 oz-in3 N·m | Shaft/Gear Type - Right-Angle Spur / Face Gear | Gear Ratio (X:1) - 30 :1 | Shaft - Single | Electromagnetic Brake - Equipped | Connection Type - Connector | Cable Direction - Down | $942.00 | CAD - |
| AZM46MKH-FC30UA AZM46MKH-FC30UA/Asset/azm46mch-fc_ua-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
|
Holding Torque - 420 oz-in3 N·m | Shaft/Gear Type - Right-Angle Spur / Face Gear | Gear Ratio (X:1) - 30 :1 | Shaft - Single | Electromagnetic Brake - Equipped | Connection Type - Connector | Cable Direction - Up | $942.00 | CAD - |
| AZM46MKH-FC7.2DA AZM46MKH-FC7.2DA/Asset/azm46mkh-fc__da-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 |
Holding Torque - 99 oz-in0.7 N·m | Shaft/Gear Type - Right-Angle Spur / Face Gear | Gear Ratio (X:1) - 7.2 :1 | Shaft - Single | Electromagnetic Brake - Equipped | Connection Type - Connector | Cable Direction - Down | $942.00 | CAD - |
| AZM46MKH-FC7.2UA AZM46MKH-FC7.2UA/Asset/azm46mch-fc_ua-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
|
Holding Torque - 99 oz-in0.7 N·m | Shaft/Gear Type - Right-Angle Spur / Face Gear | Gear Ratio (X:1) - 7.2 :1 | Shaft - Single | Electromagnetic Brake - Equipped | Connection Type - Connector | Cable Direction - Up | $942.00 | CAD - |
| AZM46MKH-HS100 AZM46MKH-HS100/Asset/azm46mkh-hs__-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 |
Holding Torque - 708 oz-in5 N·m | Shaft/Gear Type - Harmonic Gear | Gear Ratio (X:1) - 100 :1 | Shaft - Single | Electromagnetic Brake - Equipped | Connection Type - Connector | Cable Direction - | $1,334.00 | CAD - |
| AZM46MKH-HS50 AZM46MKH-HS50/Asset/azm46mkh-hs__-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 |
Holding Torque - 495 oz-in3.50 N·m | Shaft/Gear Type - Harmonic Gear | Gear Ratio (X:1) - 50 :1 | Shaft - Single | Electromagnetic Brake - Equipped | Connection Type - Connector | Cable Direction - | $1,334.00 | CAD - |
| AZM46MKH-PS10 AZM46MKH-PS10/Asset/azm46mkh-ps__-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 |
Holding Torque - 210 oz-in1.50 N·m | Shaft/Gear Type - Planetary Gear | Gear Ratio (X:1) - 10 :1 | Shaft - Single | Electromagnetic Brake - Equipped | Connection Type - Connector | Cable Direction - | $922.00 | CAD - |
| AZM46MKH-PS25 AZM46MKH-PS25/Asset/azm46mkh-ps__-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 |
Holding Torque - 350 oz-in2.50 N·m | Shaft/Gear Type - Planetary Gear | Gear Ratio (X:1) - 25 :1 | Shaft - Single | Electromagnetic Brake - Equipped | Connection Type - Connector | Cable Direction - | $992.00 | CAD - |
| AZM46MKH-PS36 AZM46MKH-PS36/Asset/azm46mkh-ps__-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 |
Holding Torque - 420 oz-in3 N·m | Shaft/Gear Type - Planetary Gear | Gear Ratio (X:1) - 36 :1 | Shaft - Single | Electromagnetic Brake - Equipped | Connection Type - Connector | Cable Direction - | $992.00 | CAD - |
