The αSTEP AZ Series stepper motor offers closed loop control, substantially reduces heat generation from the motor and by incorporating the newly developed Mechanical Absolute Encoder, absolute-type positioning is available, without battery back-up or external sensors to buy. Requires αSTEP AZ Series Driver.
Item # |
Frame Size |
Driver Voltage Input Power |
Speed-Torque Characteristics |
Holding Torque |
Shaft/Gear Type |
Gear Ratio (X:1) |
Shaft |
Electromagnetic Brake |
Connection Type |
Cable Direction |
Web Price |
CAD |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| AZM46M0KH AZM46M0KH/Asset/AZM46MCH-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 Speed - Torque Characteristics |
Holding Torque - 42 oz-in0.30 N·m | Shaft/Gear Type - Round Shaft (No Gearhead) | Gear Ratio (X:1) - | Shaft - Single | Electromagnetic Brake - Equipped | Connection Type - Connector | Cable Direction - | $598.00 | CAD - ORIENTAL_2102665461:AZM46M0KH |
| AZM46AKH-FC10DA AZM46AKH-FC10DA/Asset/azm46akh-fc__da-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 |
Holding Torque - 142 oz-in1 N·m | Shaft/Gear Type - Right-Angle Spur / Face Gear | Gear Ratio (X:1) - 10 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Down | $747.00 | CAD - |
| AZM46AKH-FC10UA AZM46AKH-FC10UA/Asset/azm46_ch-fc__ua-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
|
Holding Torque - 142 oz-in1 N·m | Shaft/Gear Type - Right-Angle Spur / Face Gear | Gear Ratio (X:1) - 10 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Up | $747.00 | CAD - |
| AZM46AKH-FC20DA AZM46AKH-FC20DA/Asset/azm46akh-fc__da-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 |
Holding Torque - 280 oz-in2 N·m | Shaft/Gear Type - Right-Angle Spur / Face Gear | Gear Ratio (X:1) - 20 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Down | $747.00 | CAD - |
| AZM46AKH-FC20UA AZM46AKH-FC20UA/Asset/azm46_ch-fc__ua-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
|
Holding Torque - 280 oz-in2 N·m | Shaft/Gear Type - Right-Angle Spur / Face Gear | Gear Ratio (X:1) - 20 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Up | $747.00 | CAD - |
| AZM46AKH-FC30DA AZM46AKH-FC30DA/Asset/azm46akh-fc__da-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 |
Holding Torque - 420 oz-in3 N·m | Shaft/Gear Type - Right-Angle Spur / Face Gear | Gear Ratio (X:1) - 30 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Down | $747.00 | CAD - |
| AZM46AKH-FC30UA AZM46AKH-FC30UA/Asset/azm46_ch-fc__ua-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
|
Holding Torque - 420 oz-in3 N·m | Shaft/Gear Type - Right-Angle Spur / Face Gear | Gear Ratio (X:1) - 30 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Up | $747.00 | CAD - |
| AZM46AKH-FC7.2DA AZM46AKH-FC7.2DA/Asset/azm46akh-fc__da-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 |
Holding Torque - 99 oz-in0.7 N·m | Shaft/Gear Type - Right-Angle Spur / Face Gear | Gear Ratio (X:1) - 7.2 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Down | $747.00 | CAD - |
| AZM46AKH-FC7.2UA AZM46AKH-FC7.2UA/Asset/azm46_ch-fc__ua-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
|
Holding Torque - 99 oz-in0.7 N·m | Shaft/Gear Type - Right-Angle Spur / Face Gear | Gear Ratio (X:1) - 7.2 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Up | $747.00 | CAD - |
| AZM46AKH-HS100 AZM46AKH-HS100/Asset/azm46akh-hs__-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 |
Holding Torque - 708 oz-in5 N·m | Shaft/Gear Type - Harmonic Gear | Gear Ratio (X:1) - 100 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - | $1,138.00 | CAD - |
| AZM46AKH-HS50 AZM46AKH-HS50/Asset/azm46akh-hs__-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 |
Holding Torque - 495 oz-in3.50 N·m | Shaft/Gear Type - Harmonic Gear | Gear Ratio (X:1) - 50 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - | $1,138.00 | CAD - |
| AZM46AKH-PS10 AZM46AKH-PS10/Asset/azm46akh-ps__-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 |
Holding Torque - 210 oz-in1.50 N·m | Shaft/Gear Type - Planetary Gear | Gear Ratio (X:1) - 10 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - | $726.00 | CAD - |
| AZM46AKH-PS25 AZM46AKH-PS25/Asset/azm46akh-ps__-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 |
Holding Torque - 350 oz-in2.50 N·m | Shaft/Gear Type - Planetary Gear | Gear Ratio (X:1) - 25 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - | $796.00 | CAD - |
| AZM46AKH-PS36 AZM46AKH-PS36/Asset/azm46akh-ps__-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 |
Holding Torque - 420 oz-in3 N·m | Shaft/Gear Type - Planetary Gear | Gear Ratio (X:1) - 36 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - | $796.00 | CAD - |
| AZM46AKH-PS5 AZM46AKH-PS5/Asset/azm46akh-ps__-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 |
Holding Torque - 142 oz-in1 N·m | Shaft/Gear Type - Planetary Gear | Gear Ratio (X:1) - 5 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - | $726.00 | CAD - |
| AZM46AKH-PS50 AZM46AKH-PS50/Asset/azm46akh-ps__-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 |
Holding Torque - 420 oz-in3 N·m | Shaft/Gear Type - Planetary Gear | Gear Ratio (X:1) - 50 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - | $796.00 | CAD - |
| AZM46AKH-PS7.2 AZM46AKH-PS7.2/Asset/azm46akh-ps__-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 |
Holding Torque - 210 oz-in1.50 N·m | Shaft/Gear Type - Planetary Gear | Gear Ratio (X:1) - 7.2 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - | $726.00 | CAD - |
| AZM46AKH-TS10 AZM46AKH-TS10/Asset/azm46akh-ts___-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 Speed - Torque Characteristics |
Holding Torque - 240 oz-in1.70 N·m | Shaft/Gear Type - Taper Hobbed Gear | Gear Ratio (X:1) - 10 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Down | $589.00 | CAD - |
| AZM46AKH-TS10L AZM46AKH-TS10L/Asset/azm46a_h-ts3__-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
Speed - Torque Characteristics |
Holding Torque - 240 oz-in1.70 N·m | Shaft/Gear Type - Taper Hobbed Gear | Gear Ratio (X:1) - 10 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Left | $589.00 | CAD - |
| AZM46AKH-TS10R AZM46AKH-TS10R/Asset/azm46akh-ts___-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
Speed - Torque Characteristics |
Holding Torque - 240 oz-in1.70 N·m | Shaft/Gear Type - Taper Hobbed Gear | Gear Ratio (X:1) - 10 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Right | $589.00 | CAD - |
| AZM46AKH-TS10U AZM46AKH-TS10U/Asset/azm46akh-ts___-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
Speed - Torque Characteristics |
Holding Torque - 240 oz-in1.70 N·m | Shaft/Gear Type - Taper Hobbed Gear | Gear Ratio (X:1) - 10 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Up | $589.00 | CAD - |
| AZM46AKH-TS20 AZM46AKH-TS20/Asset/azm46akh-ts___-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
 Speed - Torque Characteristics |
Holding Torque - 280 oz-in2 N·m | Shaft/Gear Type - Taper Hobbed Gear | Gear Ratio (X:1) - 20 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Down | $589.00 | CAD - |
| AZM46AKH-TS20L AZM46AKH-TS20L/Asset/azm46a_h-ts3__-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
Speed - Torque Characteristics |
Holding Torque - 280 oz-in2 N·m | Shaft/Gear Type - Taper Hobbed Gear | Gear Ratio (X:1) - 20 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Left | $589.00 | CAD - |
| AZM46AKH-TS20R AZM46AKH-TS20R/Asset/azm46akh-ts___-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
Speed - Torque Characteristics |
Holding Torque - 280 oz-in2 N·m | Shaft/Gear Type - Taper Hobbed Gear | Gear Ratio (X:1) - 20 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Right | $589.00 | CAD - |
| AZM46AKH-TS20U AZM46AKH-TS20U/Asset/azm46akh-ts___-img.jpg | Frame Size - 1.65 in42 mm | Driver Voltage Input Power - DC |
Speed-Torque Characteristics
Speed - Torque Characteristics |
Holding Torque - 280 oz-in2 N·m | Shaft/Gear Type - Taper Hobbed Gear | Gear Ratio (X:1) - 20 :1 | Shaft - Single | Electromagnetic Brake - Not Equipped | Connection Type - Connector | Cable Direction - Up | $589.00 | CAD - |
