DC Input AR Series 2.36 in. (60 mm) NEMA 24 Closed Loop Stepper Motors

The AR Series stepper motor adopts our AlphaStep technology closed loop control so the motor does not lose synchronism even when subjected to abrupt load fluctuation or acceleration. Requires AlphaStep AR Series Driver.

2.36 in. (60 mm) Frame Size
Closed Loop
DC Input
Single or Double Shaft
Geared Type Available
Electromagnetic Brake Type Available

26 - 44 of 44 | Results Per Page | View | Unit of Measure

1 2

Request Information Compare Items Search by Specification

Clear Filter

Shaft/Gear Type

Round Shaft with Flat (No Gearhead)
Taper Hobbed Gear
Planetary Gear
Harmonic Gear

Gear Ratio (X:1) (:1)

Shaft

Single
Double

Electromagnetic Brake

Equipped
Not Equipped

Item #	Frame Size	Driver Voltage Input Power	Speed-Torque Characteristics	Holding Torque	Shaft/Gear Type	Gear Ratio (X:1)	Shaft	Electromagnetic Brake	Web Price	CAD

ARM66MK-T20	- 2.36 in60 mm	- DC	Speed - Torque Characteristics	- 480 oz-in3.5 N·m	- Taper Hobbed Gear	- 20 :1	- Single	- Equipped	$625.00	- ORIENTAL_2102665461:ARM66MK-T20
ARM66MK-T30	- 2.36 in60 mm	- DC	Speed - Torque Characteristics	- 560 oz-in4 N·m	- Taper Hobbed Gear	- 30 :1	- Single	- Equipped	$625.00	- ORIENTAL_2102665461:ARM66MK-T30
ARM66MK-N5	- 2.36 in60 mm	- DC	Speed - Torque Characteristics	- 480 oz-in3.5 N·m	- Planetary Gear	- 5 :1	- Single	- Equipped	$989.00	- ORIENTAL_2102665461:ARM66MK-N5
ARM66MK-N7.2	- 2.36 in60 mm	- DC	Speed - Torque Characteristics	- 560 oz-in4 N·m	- Planetary Gear	- 7.2 :1	- Single	- Equipped	$989.00	- ORIENTAL_2102665461:ARM66MK-N7.2
ARM66MK-N10	- 2.36 in60 mm	- DC	Speed - Torque Characteristics	- 704 oz-in5 N·m	- Planetary Gear	- 10 :1	- Single	- Equipped	$989.00	- ORIENTAL_2102665461:ARM66MK-N10
ARM66MK-N25	- 2.36 in60 mm	- DC	Speed - Torque Characteristics	- 1120 oz-in8 N·m	- Planetary Gear	- 25 :1	- Single	- Equipped	$1,145.00	- ORIENTAL_2102665461:ARM66MK-N25
ARM66MK-N36	- 2.36 in60 mm	- DC	Speed - Torque Characteristics	- 1120 oz-in8 N·m	- Planetary Gear	- 36 :1	- Single	- Equipped	$1,145.00	- ORIENTAL_2102665461:ARM66MK-N36
ARM66MK-N50	- 2.36 in60 mm	- DC	Speed - Torque Characteristics	- 1120 oz-in8 N·m	- Planetary Gear	- 50 :1	- Single	- Equipped	$1,145.00	- ORIENTAL_2102665461:ARM66MK-N50
ARM66MK-PS5	- 2.36 in60 mm	- DC	Speed - Torque Characteristics	- 490 oz-in3.5 N·m	- Planetary Gear	- 5 :1	- Single	- Equipped	$774.00	- ORIENTAL_2102665461:ARM66MK-PS5
ARM66MK-PS7	- 2.36 in60 mm	- DC	Speed - Torque Characteristics	- 560 oz-in4 N·m	- Planetary Gear	- 7.2 :1	- Single	- Equipped	$774.00	- ORIENTAL_2102665461:ARM66MK-PS7
ARM66MK-PS10	- 2.36 in60 mm	- DC	Speed - Torque Characteristics	- 710 oz-in5 N·m	- Planetary Gear	- 10 :1	- Single	- Equipped	$774.00	- ORIENTAL_2102665461:ARM66MK-PS10
ARM66MK-PS25	- 2.36 in60 mm	- DC	Speed - Torque Characteristics	- 1130 oz-in8 N·m	- Planetary Gear	- 25 :1	- Single	- Equipped	$848.00	- ORIENTAL_2102665461:ARM66MK-PS25
ARM66MK-PS36	- 2.36 in60 mm	- DC	Speed - Torque Characteristics	- 1130 oz-in8 N·m	- Planetary Gear	- 36 :1	- Single	- Equipped	$848.00	- ORIENTAL_2102665461:ARM66MK-PS36
ARM66MK-PS50	- 2.36 in60 mm	- DC	Speed - Torque Characteristics	- 1130 oz-in8 N·m	- Planetary Gear	- 50 :1	- Single	- Equipped	$848.00	- ORIENTAL_2102665461:ARM66MK-PS50
ARM66MK-H50	- 2.36 in60 mm	- DC	Speed - Torque Characteristics	- 768 oz-in5.5 N·m	- Harmonic Gear	- 50 :1	- Single	- Equipped	$1,319.00	- ORIENTAL_2102665461:ARM66MK-H50
ARM66MK-H100	- 2.36 in60 mm	- DC	Speed - Torque Characteristics	- 1120 oz-in8 N·m	- Harmonic Gear	- 100 :1	- Single	- Equipped	$1,319.00	- ORIENTAL_2102665461:ARM66MK-H100
ARM69AK	- 2.36 in60 mm	- DC	Speed - Torque Characteristics	- 280 oz-in2 N·m	- Round Shaft with Flat (No Gearhead)	-	- Single	- Not Equipped	$257.00	- ORIENTAL_2102665461:ARM69AK
ARM69BK	- 2.36 in60 mm	- DC	Speed - Torque Characteristics	- 280 oz-in2 N·m	- Round Shaft with Flat (No Gearhead)	-	- Double	- Not Equipped	$261.00	- ORIENTAL_2102665461:ARM69BK
ARM69MK	- 2.36 in60 mm	- DC	Speed - Torque Characteristics	- 280 oz-in2 N·m	- Round Shaft with Flat (No Gearhead)	-	- Single	- Equipped	$493.00	- ORIENTAL_2102665461:ARM69MK
